MODEL |
AL-Vertical 5KW.H |
AL-Vertical 10KW.H |
|
COMPREHENSIVE PARAMETERS |
||
|
Battery Voltage |
40V~58.4V |
|
|
Storage Capacity |
5120Wh |
10240Wh |
|
Weight |
75.2Kg |
132.7Kg |
|
Colour |
White |
|
|
External Dimension(mm) |
830*600*210 |
1150*600*210 |
|
Warranty |
5 Years |
|
|
BATTERY MODULE PARAMETERS |
||
|
Type of batter |
LFE |
|
|
Capacity |
102Ah |
|
|
Battery Cycle Life |
4000 |
|
|
Modular Structure |
1P16S |
1P16S*2 |
|
OVERALL CHARACTERISTIC |
||
|
Capacity for assembled cell discharging by 0.2C |
≥100Ah |
|
|
Standard Charge Condition |
Charge with 0.5C constant current and 58.4Vconstant voltage, charge to 58.4V,continue charging till current declineto ≤0.01C |
|
|
Maximum Charge Current Maximum Discharge Current |
100A |
|
|
Internal Resistance |
≤80mΩ Assemblage Impedance |
|
|
Cycle Life |
≥4000@25℃，80%EOL |
|
|
Recommend Charging Temperature |
0℃～50℃ |
|
|
Recommend Discharging Temperature Storage Temperature |
-15℃～50℃ |
|
|
Humidity |
0-90% |
|
|
Maximum Altitude |
3000m |
|
|
FUNCTIONAL CONFIGURATION |
||
|
LED Panel (Light Emitting Diode) |
YES |
|
|
Communication |
RS485，CAN，RS232 |
|
|
IP Rating |
IP21 |
|
|
Inverter |
5KW |
|
|
LED Power Display |
Traffic Light Display |
|
|
BMS Control |
Control Battery Performance |
|
|
Package Size (mm) |
Inverter : 675*395*275 ; Battery : 675*515*265 ; Base : 610*220*95 |
|
|
CERTIFICATION |
||
|
Safety |
IEC62109-1, IEC62109-2,UL1741 |
|
|
EMC |
EN61000-6-1, EN61000-6-3, FCC 15 class B |
|
|
RoHS |
Yes |
|
A Solar Storage System is an innovative solution. It consists of solar panels to capture sunlight and convert it into electricity. The storage component, like batteries, stores the excess energy generated. This allows for a continuous power supply, even when the sun isn't shining. It's an environmentally - friendly option, reducing reliance on traditional power grids and saving on energy costs.
